BTP7 is a versatile sheet that can be uses for various structures such as garage doors, fence covers, sheds and fences.
Description
The BTP7 trapezoidal sheet is a versatile material designed to create eaves soffits, but it offers much more than that. Thanks to the variety of colours and coatings available, it is perfect not only for eaves, but also for structures such as garage doors, fence covers, sheds and fences. Take advantage of our offer and tailor the BTP7 trapezoidal sheet to your individual needs.
Information from Manufacturer Balex
Gallery
Attributes
Physical Specifications
| Property | Value |
|---|---|
| Application | Eaves, wall |
| Name | Box profile sheet BTP7 |
| Steel grade | S250GD |
| Sheet thickness [mm] | 0.40 / 0.50 |
| Max. sheet length [mm] | 2000, 3000, 4000 |
Corrosion Resistance by Coat
| Polyester 25 µm | Polyester 35 µm / Mat | Polyurethane 55 µm | |
|---|---|---|---|
| Metallic coat | Min. Z225 or equivalent | Min. Z225 or equivalent | Min. Z225 or equivalent |
| Corrosion resistance (external) RC | RC3 | RC4 | RC5* |
| Corrosion resistance (internal) AC | AC3 | up to AC4* | up to AC5* |
(*) Confirmation of corrosion resistance class RC/AC only by the steel supplier after analysis of the environmental questionnaire (via the Quality Department).
(**) Transport, assembly, cleaning, maintenance in accordance with Balex Metal recommendations.
